משאבה צנטפורגלית למים PM 50

משאבה צנטפורגלית למים PM 50


Selfpriming volumetric water pump able to offer high pressions in relation to comparatively low powers and which have particularly steady operating curves. It is qualified in domestic fittings, to increase the system pressure in aqueducts and for automatic water distribution by small autoclave tanks or by hydrosphere units. For the correct functioning of the pump, use clean water, or non-agressive liquids only, without sand or other solid impurities.

Limiti di impiego

- Liquid temperature up to 35°C (for home use according to EN 60335-2-41) - Temperature max. liquid: 60°C (for other uses) - Ambient temperature up to 40°C - Total suction lift up to 7 mt. - Continuous duty

Motore

- Two-Pole induction motor (n = 2850 min-1) - Insulation Class F - Protection IP 44

Materiali

- Pump body: Cast Iron - Motor Support: Cast Iron - Impeller: Brass - Shaft with rotor: Stainless Steel AISI 304 - Mechanical seal: Ceramic/Graphite/NBR
מק"ט : 611500
